Monitor Audio Gold 500 6G

The flagship Gold 500 6G is engineered to deliver the very highest levels of performance. It features the latest MPD III high-frequency transducer alongside an HDT, C-CAM 3-inch mid-driver and twin 8-inch bass drivers.

The Gold 500 6G is the flagship model of the new Gold Series 6G. It represents the highest-levels of performance and system design at the price point, and within this competitive market segment. Designed to house the latest MPD III high-frequency transducer alongside the new 3-inch mid-driver and powerful twin 8-inch bass drivers, each of which benefit from the latest HDT, C-CAM cone technology and hugely powerful motor systems. The Gold 500 6G is a worthy flagship for such a prestigious range; a formidable acoustic treat for the ears as well as the eyes.

Key Features

• Three-way design
• 1 x MPD III high-frequency transducer
• 1 x 3-inch mid-driver featuring HDT, C-CAM cone technology
• Steel mid-pod enclosure with die-cast aluminium baffle
• 2 x 8-inch bass drivers featuring HDT, C-CAM cone technology
• New crossover design utilising carefully selected high-quality capacitors
• Ported cabinet design using HiVe II port technology and through-bolt technology
• All-new cast aluminium outriggers and plinth/spike assembly featuring a new steel plate for greater structural integrity and improved stability
• Finishes available: Macassar wood veneer, High-Gloss Black and Satin White
• Individual driver ‘Magnetic grilles’ included

Specification

• System Format
  3-way
• Sensitivity (2.83v @ 1m, Free-Field)
  88.5 dB
• Sensitivity (2.83v @ 1m, Installed)
  N/A
• Recommended Amplifier Power (RMS into 4 Ohm, Music Signal)
  130 – 600 W
• Continuous Power Handling (CTA 426-B)
  300 W
• Nominal Impedance
  4 Ohms
• Minimum Impedance (20Hz to 20kHz)
  4 Ohms @ 150 Hz
• Drive Unit Complement
  2 x 8” (203 mm) HDT C-CAM Bass Drivers
  1 x 3” (76 mm) HDT C-CAM Mid-Range Driver
  1 x MPD III Tweeter
• Frequency Response Free-Field (-6dB)
  44 Hz – 60 kHz
• Frequency Response, In-Room (-6dB)
  25 Hz – 60 kHz
• Maximum Peak SPL (AES75, Z-weighted)
  122 dB
• Bass Alignment
  HiVe II Ported
• Port Tuning Frequency
  33 Hz
• Crossover Frequency
  LF/MF: 700 Hz
  MF/HF: 2.6 kHz
• External Dimensions with all accessories fitted (H x W x D)
  1155 x 383 x 475 mm (451/2 x 151/16 x 1811/16”)
• Weight (each)
  26.5 kg (58 lb 7 oz)
• Sold As
  Pair
