Marantz AV 30

Description

AV 30 delivers exceptional performance and capability for large media rooms and dedicated home theater systems. This 11.4-channel balanced AV preamplifier features Marantz HDAM discrete circuitry and boasts seven HDMI inputs, each of which is 8K Ultra HD compatible. Powered by HEOS™ for high-resolution music streaming, AV 30 includes room correction with Audyssey MultEQ XT32 and optional Dirac Live. It delivers Dolby Atmos, DTS:X Pro, AURO-3D, and features multiple inputs and balanced pre-amp outputs for all channels, including four independent subwoofers.

• Crafted in Shirakawa, Japan
• 11.4 Channels
• 7 HDMI Inputs plus eARC
• 8K and Dolby Atmos
• 3D Audio
• Powered by HEOS™

Elevated Listening Begins Here

AV 30 is engineered to bring exceptional cinema sound into your home. Advanced Marantz technology and expert craftsmanship ensure your entertainment is always delivered with powerful precision—from an elegant, timeless design.

Exceptional Performance

Enjoy every movie moment with immersive realism and lifelike detail. AV 30 delivers an outstanding theater experience—in your home.

Ultimate Flexibility

The 11.4-channel onboard processing supports a wide range of speaker configurations. Perfect for all forms of immersive audio suitable for even large home theater systems.

Technology Leader

AV 30 comes packed with support for the latest high-resolution movie formats, plus 8K video compatibility, room optimization, and Powered by HEOS™ technology to simplify and elevate your listening.

Timeless Design

A modern expression of timeless design principles, AV 30 features the iconic Marantz porthole, premium materials, and subtle sidelights that illuminate the front panel.

For the Soundtrack of Your Life

HEOS® has a search feature that lets you find and stream from the world’s leading music platforms, including TIDAL, Pandora, and Amazon Music HD.

Multichannel Surround

DTS
DTS-HD Master Audio, DTS:X,
DTS Virtual:X, DTS Neural:X
Dolby
Dolby TrueHD, Dolby Atmos,
Dolby Atmos Height Virtualization,
Dolby Surround
IMAX
IMAX Enhanced
Auro 3D / 360 Reality Audio / MPEG H
Yes / Yes / Yes
Multichannel Stereo
Yes
Max Number of Processing (Pre-amp) Channels
11.4

Sound Enhancements

Copper-Plated Chassis / Toroidial Power Transformer
Yes / Yes
Current Feedback Topology / Hyper Dynamic Amplifier Modules (HDAM)
Yes / Yes (HDAM-SA2)
Pure Direct / Gold-Plated RCA Terminals
Yes / Yes
Clock Jitter Reducer
Yes
Dirac Live upgradability
Yes
Compressed Audio Enhancer: MDAX2
Yes
Audyssey Dynamic EQ / Dynamic Volume / Audyssey LFC
Yes / Yes / Yes
Audyssey
MultEQ XT32

Network

Wi-Fi / Bluetooth / Ethernet
Yes / Yes / Yes
HEOS Multi-Room and Streaming
Yes
Bluetooth Retransmit for Bluetooth Headphones
Yes
Apple HomePod
Yes
Lossy formats
MP3, WMA, AAC
Lossless formats
FLAC, FLAC HD 192/24,
ALAC, ALAC 192/24,
WAV, WAV 192/24
DSD Audio Streaming
Yes (up to DSD5.6)
Gapless Playback
FLAC, ALAC, WAV, DSD
TuneIn / AirPlay 2 / Spotify
Yes / Yes / Yes
Roon-Ready
Yes
Other Streaming Services*
Amazon Music / TIDAL /
Deezer / Napster / SoundCloud
Compatible with Remote App for Smartphones
Marantz AVR Remote
Compatible with Remote App for Tablets
Android / iOS / Amazon Kindle

HDMI

Total HDMI Inputs
7
HDCP 2.3 Support
Yes
HDMI Outputs: Main / Zone
2 / 1
HDMI Scaling
1080P/4K to 8K
GUI Overlay on HDMI
Yes
HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB
Yes / Yes
8K/60Hz AB / 4K/120Hz AB Pass-Through In/Out
7 / 2 (up to 40 Gbps)
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
Yes / Yes / Yes / Yes / Yes
Enhanced ARC
Yes
ALLM (Auto Low Latency Mode) Pass-Through for Gaming
Yes
Variable Refresh Rate / Quick Frame Transport
Yes / Yes
HDMI Pass-Though in Standby Mode
Yes
DSD Audio Capability
Yes
Auto LipSync
Yes

Inputs Outputs

Composite In / Out
2 / 0
Component In / Out
1 / 0
HDMI In / Out
7 / 3
Multi-Room Video Out: Video / HDMI
No / Yes
Analogue In
6 (1x XLR)
Phono (MM) In
Yes
Digital In: Optical / Coaxial
2 / 2
Multi-Room Out: analog / digital
2 / 0
Multichannel Pre-Amp Out
Yes (11.4 RCA, 11.4 XLR)
Subwoofer Out
4 (independent)
Speaker A / B
Assignable Pre-Out
Bi-Amp Drive
Assignable Pre-Out
Front USB Input / USB Audio
Yes / Yes
USB Power Supply (Rear)
Yes
AM/FM Tuner
Yes

Multi-Room CI

HEOS Multi-Room Integrated
Yes
HEOS Link Compatibility: IR/ IP
Yes / Yes
Multi-Room Zones
3
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analogue
Yes (2 ch) / Yes (2 ch) / Yes / Yes
Zone Audio Output: Speaker / Pre-Out
No / Yes
Zone HDMI Output from HDMI Source
Yes
IP Control / RS232 Control / Web Control / App Control
Yes / Yes / Yes / Yes
IR Flasher In / Marantz Remote Bus
Yes / Yes
DC Trigger Output
3
HDMI Diagnostics
Yes

Others

Auto Speaker Setup by Microphone
Audyssey MultEQ XT32
Dirac Live (Upgrade)
Front Display
2-Line FLD, Port Hole OLED
Graphic User Interface
Modern HD GUI
GUI Languages
9
Setup Assistant / Smart Select
Yes / Yes
Firmware Update by Network / USB
Yes / Yes
Variable Cross Over / Optimized Bass Redirection / Bass Sync
Yes / Yes / Yes
Auto Power Off / Sleep Timer
Yes / Yes

General

Metal Front Panel
Yes
System Remote Control
RC053SR
Backlit
Yes
Power Consumption
80 W
Standby Consumption
0.2 W
CEC Standby Consumption in W
0.5 W
Network Standby Consumption
2.0 W
Maximum Dimensions
Antenna: Horizontal:(W x D x H)
Antenna: Vertical :(W x D x H)
w/o Antenna: (W x D x H)

17.4 × 16.3 × 7.5 in.
17.4 × 16.3 × 10.0 in.
17.4 × 15.6 × 7.5 in.
Weight
24.5 lbs.
What’s in the box
Main unit, remote control,
batteries, AM/FM antennas,
wire labels, quick start guide,
Audyssey microphone, card
board microphone stand,
2 External Detachable Antenna,
AC cord
