Beskrivning
Since its inception in 1987, Esoteric has been at the forefront of innovation as a high-end audio brand from Japan, continually pushing the boundaries of high quality sound reproduction. The Esoteric brand is known for its outstanding acoustic engineering that has sustained its reputation and prestige, its massive investment without regard to cost, its ”museum quality” craftsmanship, and its beautiful designs worthy of music reproduction. ”Grandioso” is the top model in each product category that has reached the highest level of quality defined by the brand.
In classical music, a phrase that indicates how a piece of music should be played is called a conception motto. For example, ”cantabile” (as if singing), ”legato” (smoothly), and so on. A flagship model should have the dignity and stature of a top-of-the-line product. We named it ”grandioso” (grand, majestic, dignified), which we likened to the motto of classical music. Grandioso has brought a number of highly original innovations to the world of high-end audio, including the legendary VRDS-ATLAS Super Audio CD transport mechanism, the Master Sound Discrete DAC and the Master Sound Discrete Clock, which consist of unique discrete circuits.
Finally, three SE models are now available with new discrete clock technology and improved analog circuitry in the DAC. We are proud of our brand and always strive for the best sound.
The SE model we are releasing this time reflects every conceivable technological accumulation from the time the original model was launched to the present. Enjoy the enhanced presence, dynamics, and beautifully organic and musical textures of the three new SE models.
- “Master Sound Discrete DAC” – In-house developed FPGA, 64bit/512Fs Delta-Sigma modulator
- Up-graded DAC board with specially selected quality parts including IDM-01
- “ES-Link5” ultra-wide range digital transimission (DSD 22.5MHz, PCM 768kHz/48bit)
- “Master Sound Discrete Clock for Digital Player” – in-house developed discrete clock module
- “Esoteric-HCLD” output buffer amplifier (slew rate: 2,000V/μs)
- “ES-Link Analog” current signal transmission output
- Clock sync function
- Low-feedback discrete DC regulators
- Two independent toroidal power supply transformers/ch
- MQA decorder / up-convert function
- USB input (DSD 22.5MHz, PCM 768kHz/32bit, asynchronous transmission)
- Semi-floating top panel
- Redesigned pinpoint foot
- Version up service from the Grandioso D1X to the D1X SE is available.
* A discrete designed power regulator circuit that minimizes an amount of feedback while stbilizing supplying the power, reaalizes open and wide-spreading sound.
Spec description
Digital audio inputs | |
ES-LINK | 2 |
Input signal formats | Linear PCM (ES-LINK5 format) |
44.1k to 768kHz 48bit | |
DSD (ES-LINK5 format) | |
2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz | |
XLR | 1 |
Input level | 5.0Vp-p |
Input impedance | 110Ω |
Input signal formats (DUAL connection) |
Linear PCM (DUAL AES format) |
88.2k to 384kHz, 16bit to 24bit | |
Linear PCM (ES-LINK3 format) | |
88.2k to 192kHz, 48bit | |
DSD (ES-LINK1, ES-LINK2, DoP format) | |
2.8MHz | |
Input signal formats (SINGLE connection) |
Linear PCM (AES/EBU format) |
32k to 192kHz, 16bit to 24bit | |
DSD (ES-LINK1, ES-LINK2, DoP format) | |
2.8MHz | |
RCA | 2 |
Input level | 0.5Vp-p |
Input impedance | 75Ω |
Input signal formats | Linear PCM (IEC60958 format) |
32k to 192kHz, 16bit to 24bit | |
DSD (DoP format) | |
2.8MHz | |
OPTICAL | 1 |
Input level | –24.0 to –14.5dBm peak |
Input signal formats | Linear PCM (IEC60958 format) |
32k to 192kHz, 16bit to 24bit | |
DSD (DoP format) | |
2.8MHz | |
USB | 1 (USB2.0 standatd) |
Input signal formats | Linear PCM 44.1k to768kHz, 16bit to 32bit |
DSD 2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz | |
Analog audio outputs | |
XLR/ESL-A | x 1 (mono) each for left and right channels |
Output impedance | 100Ω (XLR) |
Maximum outout level | 5.0Vrms (XLR, 1kHz, full scale PCM signal input, 10kΩ loaded) |
RCA | x 1 (mono) each for left and right channels |
Output impedance | 47Ω |
Maximum output level | 2.5Vrms (1kHz, full scale PCM signal input 10kΩ loaded) |
Clock input | |
BNC | x 1 each for left and right channels |
Input impedance | 50Ω |
Input level | Sine wave 0.5 to 1.0Vrms |
Frequency that can be input | 10MHz (±10ppm) |
General | |
Power supply | |
AC 220 to 240V. 50/60Hz | |
Power consumption | 20W |
External dimensions (W×H×D) | 445 × 132 × 448mm (including protrusions) |
Weight | |
Left channel | 23.1kg |
Right channel | 23.0kg |
Included accessories | Power cord × 1 HDMI cables × 2 Felt pads × 8 Owner’s manual × 1 Warranty card × 1 |
Audio performance
Frequency response | 5Hz to 30kHz (–3dB, 192kHz PCMsignal input) |
S/N ratio | 113dB |
Distortion | 0.0007% (when 1kHz, D/A converter operation mode set to M3) |
- This product is available in three different power supply variations shown in the specification section above. Make sure that the voltage shown on the rear panel matches the AC line voltage in your area.
- The shape of the AC inlet and plug of the supplied power cord depends on the voltage rating and destination country.
- Design and specification are subject to change without notice.
