Building on the iconic status of ELAC’s Debut Series, a new Reference line emerges for our exclusive dealers. The Debut Reference brings significant acoustical and visual advancements. Designed to blend with traditional or contemporary styles. Debut Reference sounds as great as it looks!
Improved Aesthetics – Reference Aesthetics
For some, looking good is as important as sounding good.
The Uni-Fi Reference has been redesigned for maximum performance and style, so it can look as good as it sounds.
proved 3-Way Design – Leap Into High End Audio
Would you ask two people to do a three person job?
Most speakers in this price range have one driver tuned for highs and another tuned for both mids and lows. The Uni-Fi Reference has three – one for each frequency range.
With an entirely new midrange driver and newly designed cast chassis, the Uni-Fi Reference is truly a step into high end audio.
Improved Crossover – Listen to a Perfect Harmony
A conductor is to an orchestra, what a crossover is to a 3-way speaker – a guide to make many sound like one.
Our improved crossover blends the Uni-Fi Reference’s three unique drivers into one harmonious sound.
Enjoy the luxury of a 3-way speaker at an unmatched price.
Pure Bliss. No Rattling -Full Perimeter Bracing
A supercar isn’t just measured by how much power it produces – it’s measured by how well it handles the power.
The all new Uni-Fi Reference adds full perimeter bracing, allowing you to push it harder with significantly reduced cabinet vibration and coloration.
Improved Bass Dynamics – Dual Flared Slot Vents
A dedicated woofer optimized with all our newly developed dual flared slot vents.
Utilizing both internal and external flares, the reference series slot vents allow for lower noise and higher bass output for improved low frequency dynamics.
Improved Drivers – Aluminum Drivers with Cast Chassis
Drastically improving low-end reproduction, our newly developed bass driver delivers improved linearity and the best low frequency response out of any of our previous Uni-Fi speakers.
With a single piece compound curvature aluminum cone and a large rear vented magnet, the new 6.5″ woofer with cast chassis will not disappoint.
Product Specifications
- Speaker Type: 3-Way Bass Reflex
- Frequency Response: 47Hz—35000Hz
- Nominal Impedance: 6 Ohms
- Sensitivity: 85db
- Crossover Frequency: 240 / 1800Hz
- Maximum Power Input: 140 Watts
- Tweeter: 1″ Soft Dome
- Midrange: 4″ Aluminum
- Woofers: 2 x 5.25″ Aluminum
- Cabinet: CARB2 Rated MDF
- Cabinet Finish: Satin White with Oak Sides or Satin Black with Walnut Sides
- Port: Dual Flared Slots
- Binding Posts: Bi-Wire 5-Way
- Dimensions (WxHxD): 20.75″ x 7.28″ x 13.15″
- Net Weight: 29.04 lbs
